Calibration 13
3.8 Normal Mode Test
After completing the above calibration procedures, you must perform a normal mode test. A current generator
capable of generating 20 mA must be connected to the COMMON and CURRENT INPUT jacks, see Figure 2.2
on page 4 (14). The
DISPLAY SELECT switch (16) should be on the CURRENT position.
1. Set the Condec Calibration Module to the NORMAL MODE position.
2. DISPLAY SELECT switch should be in the CURRENT position. The display reads 20.000 .
3.9 Self-Check Test
1. Remove the Condec Calibration Module.
2. Press the ZERO pushbutton (12) on the UPC5200/UPC5210 until the unit shows CAL . The display shows
100 to verify the unit's accuracy, then it returns to the normal mode automatically.
3. The pneumatic portion of the calibration is now complete. The pressure standard and the Condec
Calibration Module can now be disconnected.
