UPC5200/UPC5210 Operation and Maintenance Manual
Terminal Color
Normally open
Black
(C) common
Black
2. Pull shrink sleeving over switch and connections. Apply heat. Install the new switch, lock washer and nut
through the panel rear as one item. Hand tighten the trim ring from front of panel.
3. Tighten the switch mounting nut and lock washer from the rear of panel.
CAUTION: If wrench is used, do not over tighten, damage may occur to switch.
4. Install panel/chassis assembly in its enclosure as described in Section 4.2.1 on page 16.
4.2.25
Range Select Switch (PN 55924) and Display Select Switch (PN 55933), Removal and Installation
Tools required:
Phillips screwdriver
9/16" open end wrench or nutdriver
A/R soldering iron
061" hex wrench
Removal:
1. Disconnect the power cord from the power source and line filter. Remove front panel from its enclosure
as described in Section 4.2.1 on page 16, and carefully set on a bench top.
2. Remove the switch knob using a .061" hex wrench.
3. Loosen and remove the mounting nut from the panel front.
NOTE: Intensifier and Accumulator will need to be removed prior to switch removal.
4. Unsolder and remove the wires from the switch terminals.
Installation:
1. Connect and solder the wires onto their respective switch terminals:
Range Select:
Terminal Color
1
Grey
2 Violet
(C) common Green
Display Select: Terminal Color
2 Blue
(C) common
Green
(C) common
Green
2. Install the switch through the panel rear, align with front panel markings, and secure with its mounting
nut.
3. Install the switch knob using a .061" hex wrench.
4. Replace tubing and components as necessary.
5. Install panel/chassis assembly in its enclosure as described in Section 4.2.1 on page 16.
4.2.26
Zero Switch (PN 58886), Removal and Installation
Tools required:
Phillips screwdriver
11/16" open end wrench
A/R soldering iron
Removal:
1. Disconnect the power cord from the power source and line filter. Remove front panel from its enclosure
as described in Section 4.2.1 on page 16, and carefully set on a bench top.
2. Loosen the switch mounting nut and lock washer from the rear of panel.
3. Loosen and remove the trim ring from the panel front.
4. Remove switch, lock washer and nut from rear of panel.
5. Unsolder and remove the wires from the switch terminals.
