Multi-Service IronWare SDN Configuration Guide 23
53-1003034-02
Configuring OpenFlow
1
Syntax: show openflow
Displaying the OpenFlow status
If OpenFlow is enabled on a device, you can get detailed report of the OpenFlow status on that
device.
Brocade NetIron CER and Brocade NetIron CES devices:
On these devices, only Layer 2 matching mode is supported on the interfaces.
Brocade(config)# show openflow interface
Port Link Port-State Speed Tag MAC OF-portid Name Mode
1/1 Up Forward 1G No 0000.00b4.89c1 1 Layer2
1/2 Up Forward 1G No 0000.00b4.89c2 2 Layer2
1/3 Up Forward 1G No 0000.00b4.89c3 3 Layer2
Brocade MLX Series and Brocade NetIron XMR devices:
Brocade(config)# show openflow interface
Port Link Port-State Speed Tag MAC OF-portid Name Mode
1/5 Up Forward 1G No 0000.0088.0904 5 OpenFlow-A Layer2
1/7 Up Forward 1G No 0000.0088.0906 7 OpenFlow-B Layer3
1/8 Up Forward 1G No 0000.0088.0907 8 OpenFlow-C Layer3
2/1 Up Forward 1G Yes 0000.0088.0916 49 OpenFlow-E Layer2
TABLE 7 Output fields of the show openflow interface command
In addition, you can use the show interface command at the interface level. If OpenFlow is enabled
on the interface, the OpenFlow status is indicated in the output.
Brocade(config-if-e1000-1/1)# show interfaces
GigabitEthernet1/1 is down, line protocol is down
STP Root Guard is disabled, STP BPDU Guard is disabled
Hardware is GigabitEthernet, address is 0000.0034.5060 (bia 0000.0034.5060)
Configured speed auto, actual unknown, configured duplex fdx, actual unknown
Field Description
Port Indicates the port number on the device.
Link Indicates the link status.
Port-State Indicates the action to be performed on packets that reach the interface. Supported
actions include forward the packet, modify the VLAN tag, drop the packet, and send to
the controllers.
Speed Indicates the port speed.
Tag Indicates whether the interface can accept tagged packets or not.
MAC Indicates the MAC address of the port.
OF-PortID Indicates the OpenFlow port ID that is assigned to the port on the device. Port
numbers on the device are mapped to OpenFlow port IDs. For more information, see
“Behavior of ports and devices” .
Name Indicates the name assigned to the port.
Mode Indicates the OpenFlow mode enabled on the port. Ports on Brocade NetIron CER and
Brocade NetIron CES devices support only Layer 2 mode. Ports on Brocade MLX Series
and Brocade NetIron XMR devices support either Layer 2 or Layer 3 mode.
