31
P E R F O R M V A C U U M
S E N S O R C A L I B R A T I O N ?
S E L E C T Y E S O R N O
V A C C A L - S T A B L E
S E N S O R T A R G E T 1 0 0 0 M
T O G G L E P U M P W I T H # 1
P R E S S Y E S T O C A P T U R E
S E T D A T E A N D T I M E ?
# # - # # - # # # #
# # : # # : # #
S E L E C T Y E S O R N O
E N T E R P A S S W O R D
# # # #
S T A R T T O C O N T I N U E
S T O P T O E N D
P A S S W O R D A C C E P T E D
S T A R T T O C O N T I N U E
S T O P T O E N D
Or the next screen may be displayed…
P A S S W O R D R E J E C T E D
S T A R T T O R E T R Y
S T O P T O E N D
S E T T H E D A T E F O R M A T
Y Y Y Y - M M - D D ▲
M M - D D - Y Y Y Y ▼
C O N T I N U E ?
S E T T H E Y E A R
# # # # ▲
▼
C O N T I N U E ?
S E T T H E M O N T H
# # ▲
▼
C O N T I N U E ?
Press YES key if vacuum sensor calibration is
required. Otherwise, press NO key. An external
micron sensor gauge is required and must be
connected to the low side port for this procedure.
Access to vacuum sensor calibration must be verified
by service manager by entering a password.
Vacuum process will start and external sensor will be
drawn into a vacuum. Press #1 key when level
reaches 1000 micron. Micron level must hold 1000 as
shown on the external micron sensor for 1 min prior to
pressing the YES key. Press NO key to end
procedure without capturing new value.
Press YES key if adjustment to the date and time is
required. Otherwise, press NO key.
If password protection is enabled the next 3
subsequent screens will be shown. The current service
manager password is entered, default is shown, 5237.
Call RTI for assistance if password is unknown or lost.
Press START key.
If service manager password is accepted, this screen
is shown. Press START key.
If service manager password is rejected, this screen is
shown. Check the password and press START key to
retry the entry or press STOP key to end.
The format for the date is selected by pressing START
key. Change highlighted format with the ▲ or ▼ key.
Using ▲ or ▼ key, increase or decrease the year.
Press START key to continue.
Using ▲ or ▼ key, increase or decrease the month.
Press START key to continue.
