11
F I L L C Y L I N P R O C E S S
T I M E L E F T # # . # #
S T O P T O E N D
F I L L C Y L C O M P L E T E
A M T F I L L E D # # . # L B
S T O P T O E N D
The amount transferred will be displayed. Note:
Pressing the STOP key will start an internal
clearing process. This process must run to
completion to remove internal refrigerant.
The Fill Cylinder procedure is complete when desired
amount of refrigerant has been transferred. The Setup
procedure allows changing the value and is covered in
DEFAULT VALUES section in this manual.
Note: To fill to less than 18 LB (8.16 KG), close
valve on cylinder of new refrigerant and allow
procedure to complete. A minimum of 10 LB (4.53
KG) is suggested for truck service application.
AUTOMATIC OPERATION
W E I G H T = # # . # L B
A U T O M A T I C
S T A R T ?
S T A R T I N G R E F R I G E R A N T
I D E N T I F I E R
D O N O T C O N N E C T H O S E S
P L E A S E W A I T . . .
E X A M I N E I D S A M P L E
H O S E / F I L T E R F O R O I L
S T A R T T O C O N T I N U E
S
T O P T O E N D
C O N N E C T I D E N T I F I E R
S A M P L E H O S E T O L O W
S I D E
P R E S S Y E S W H E N D O N E
G A S A N A L Y S I S I S I N
P R O C E S S . . P L E A S E
W A I T
At the main menu screen, press the START key.
If the RHS980C has the optional refrigerant identifier
installed, the screen to the left and next 6 subsequent
screens will appear.
Inspect the identifier hose for traces of oil
contamination. If oil is present in the hose, remove the
contaminated hose section or replace the entire hose
assembly. See REFRIGERANT IDENTIFIER
MAINTENANCE section of manual. Press START key.
Connect refrigerant identifier hose found on the rear of
the RHS980C to the vehicle low side service port.
Press YES key.
REFRIGERANT BLENDS
The RHS980C is designed to recover, recycle and charge R134a. Take extreme precaution to ensure that other
refrigerants are not recovered into the RHS980C.
A refrigerant identifier is recommended for evaluating refrigerant in the A/C system prior to servicing.
Recovering other refrigerants will contaminate the refrigerant in the RHS980C charge cylinder.
LEAK SEALERS
Sealants and leak stop chemicals in A/C systems may cause serious damage to the RHS980C if they are present in
the refrigerant recovered intended for recovery.
Detection devices are readily available to check for the presence of these chemicals and are highly recommended
to protect the RHS980C.
Call RTI for more information about solutions for detection of refrigerant blends and leak sealers.
