10
W E I G H T = # # . # L B
C H A R G E
S T A R T ?
W E I G H T = # # . # L B
F I L L C Y L I N D E R
S T A R T ?
S T A R T I N G R E F R I G E R A N T
I D E N T I F I E R
D O N O T C O N N E C T H O S E S
P L E A S E W A I T . . .
E X A M I N E I D S A M P L E
H O S E / F I L T E R F O R O I L
S T A R T T O C O N T I N U E
S
T O P T O E N D
C O N N E C T I D E N T I F I E R
S A M P L E H O S E T O L O W
S I D E
P R E S S Y E S W H E N D O N E
G A S A N A L Y S I S I S I N
P R O C E S S . . P L E A S E
W A I T
R E M O V E I D E N T I F I E R
S A M P L E H O S E F R O M L O W
S I D E
P R E S S Y E S W H E N D O N E
I D R E S U L T S :
R 1 3 4 : # # . # % , A I R : # # . # %
H C : # # . # % P R E S S N O T O
R E J E C T , Y E S T O A C C E P T
> 5 % A I R S U G G E S T S
E X C E S S O I L I N S A M P L E
H O S E / F I L T E R .
R E M E D Y
B E F O R E U S E . C O N T I N U E ?
C O N N E C T H O S E T O
S O U R C E T A N K
O P E N V A L V E
S T A R T ?
F I L L C Y L I N P R O C E S S
A M T F I L L E D # # . # L B
S T O P T O E N D
Press ▼ key.
Press START key. If the internal cylinder capacity
is equal to or greater than the target amount
shown in DEFAULT VALUES, the FILL CYLINDER
process will not be available from the main menu.
If the RHS980C has a refrigerant identifier installed,
the screen to the left and next 3 subsequent screens
will appear. The refrigerant identifier is an optional
item and can be installed in the field. Contact RTI for
more information.
Inspect the identifier hose for traces of oil
contamination. If oil is present in the hose, remove the
contaminated hose section or replace the entire hose
assembly. See REFRIGERANT IDENTIFIER
MAINTENANCE section of manual. Press START key.
Connect refrigerant identifier hose found on the rear of
the RHS980C to the cylinder of new refrigerant. Unit
includes an adapter to convert the ½ inch Acme fitting
on the cylinder to low side coupler. Cylinder of new
refrigerant must be upright with valve at top of
tank. Press YES key.
Sample of new cylinder refrigerant is processed and
the hose and coupler must be removed. Press
START key.
This shows the results from the identifier refrigerant
sample processed. Select NO key to reject these
results or YES key to accept the results. Pressing NO
will return to the initial screen.
If the results from the refrigerant identification show an
air percentage above 5%, this screen will appear.
Inspect the id filter, sample hose and coupler filter prior
to the next identification to ensure these devices are
free of oil contamination. See REFRIGERANT
IDENTIFIER MAINTENANCE section for more
information.
This is a reminder that the cylinder of new refrigerant
must be connected to the yellow hose on the rear of
the RHS980C. Press START key.
Refrigerant will be transferred from the cylinder on the
rear platform into the internal charge cylinder of the
RHS980C. Cylinder of new refrigerant must be
upside down with valve at bottom of tank.
