DIMENSIONAL DATA
Table 1 - Tubular Duct Furnace Dimensions
Figure 1 - Tubular Duct Furnace Dimensions
Unit Capacity
100
150
200
250
300
350
400
Dimensional Data - inches (mm)
“A” Overall Unit Height
10.3
13.7
17
20.2
23.5
26.7
30
(262)
(348)
(432)
(513)
(597)
(678)
(762)
“B” Height to Centerline Flue
7.6
10.5
11.9
6.8
8.4
10
11.6
(193)
(267)
(302)
(173)
(213)
(254)
(295)
“C” Height to Gas Connection
2.5
3.7
5.3
7
7
8.7
10.3
(64)
(94)
(135)
(178)
(178)
(221)
(262)
“D” Opening Height, Front & Rear
8.5
11.7
15
18.2
21.5
24.7
28
(216)
(297)
(381)
(462)
(546)
(627)
(711)
“E” Overall Unit Depth
32.7
32.7
32.7
33.5
33.5
33.5
33.5
(831)
(831)
(831)
(851)
(851)
(851)
(851)
“F” Flue Size Diameter
5
5
5
6
6
6
6
(127)
(127)
(127)
(152)
(152)
(152)
(152)
“G” Air Inlet Size Diameter
5
5
5
6
6
6
6
(127)
(127)
(127)
(152)
(152)
(152)
(152)
Gas Inlet, Natural Gas - inch
1/2
1/2
1/2
3/4
3/4
3/4
3/4
Gas Inlet, LP Gas - inch
1/2
1/2
1/2
3/4
3/4
3/4
3/4
Approximate Unit Weight - lb
160
221
250
270
296
321
355
(kg)
(73)
(100)
(113)
(122)
(134)
(146)
(161)
Approximate Ship Weight - lb
270
331
360
403
429
454
488
(kg)
(122)
(150)
(163)
(183)
(195)
(206)
(221)
65.500
16.5
HANGING
LOCATION
48.7
OPENING
FRONT & REAR
D
OPENING
FRONT & REAR
E
47.50
15.251
30.500
27.50
1.50
C
4
7.197
G
D9362
10.3
1.5
1.5
GAS
CONNECTION
1.000
32.5
PEEP
HOLE
A
F
REAR VIEW
TOP VIEW
SIDE VIEW
B
POWER
CONNECTION
ACCESS PANEL
D9362
