Yokogawa EXAxt PH450 4-Wire Analyzer for pH and ORP - Manual (Page 33)

25
IM 12B07C05-01E
5
MENU
STRUCTURE
COMMISSIONING
Menu Parameter Default Range
values min. max.
Manual Manual Temp. 25ºC, 77ºF -30ºC, -22ºF 139ºC, 284ºF
Temp. comp.
Reference Temp. 25ºC, 77ºF 0ºC, 32ºF 100ºC, 211ºF
Temp. Coef
T.C. pH 0.0 pH/ºC, 0.0 pH/ºF -0.1 pH/ºC, -0.06 pH/ºF 0.1 pH/ºC, 0.06 pH/ºF
Temp. Coef T.C. ORP 0.0 mV/ºC, 0.0 mV/ºF -10 mV/ºC, -6 mV/ºF 10 mV/ºC, 6 mV/ºF
Matrix Temp. Ranges – -30ºC, -22ºF 139ºC, 284ºF
Matrix pH Ranges – -1.99 pH 16 pH
Note!
‘Sensor type’ and ‘Measurement’ determine the rest of the HMI menu structure.
