QPAC User's Guide 9 Chapter 2: Install & Wire
Case Style C
Mounting
QPAC Case
Style C, Q32,
150, 200, 300A,
3-Phase, 2-Leg
Mounting Footprint.
QPAC Case Style C,
Q33, 150, 200, 300A,
3-Phase, 3-Leg Mounting
Footprint.
ç
CAUTION:
Mount the QPAC verti-
cally (height dimension
vertical) for proper
cooling. Failure to do
so could result in power
control malfunction.
∫
WARNING: Shock Hazard
Heatsinks are electrically
Live.
89mm
(3.50 in)
356mm
(14.00 in)
4 PL
P
U
MOUNT
FAN FAN
16mm
(0.63 in)
298mm
(11.75 in)
33mm
(13.00 in)
178mm
(7.00 in)
10mm (0.375 in)
92mm
(3.63 in)
533mm
(21.00 in)
4 PL
P
U
MOUNT
FAN FAN
16mm
(0.63 in)
298mm
(11.75 in)
33mm
(13.00 in)
178mm
(7.00 in)
10mm (0.375 in)
FAN
178mm
(7.00 in)
∫
