8 QPAC User's Guide Chapter 2: Install & Wire
Model Amps Height Width Depth Fans Fuses
QPAC-01
QPAC-01
QPAC-01 150
200
300 330mm (13 in)
330mm (13 in)
330mm (13 in) 175mm (6.9 in)
175mm (6.9 in)
175mm (6.9 in) 260mm (10.25 in)
260mm (10.25 in)
260mm (10.25 in) 1
1
1 on heat sink
on heat sink
on heat sink
QPAC-32
QPAC-32
QPAC-32 150
200
300 330mm (13 in)
330mm (13 in)
330mm (13 in) 348mm (14.0 in)
348mm (14.0 in)
348mm (14.0 in) 260mm (10.25 in)
260mm (10.25 in)
260mm (10.25 in) 2
2
2 on heat sink
on heat sink
on heat sink
QPAC-33
QPAC-33
QPAC-33 150
200
300 330mm (13 in)
330mm (13 in)
330mm (13 in) 533mm (21.0 in)
533mm (21.0 in)
533mm (21.0 in) 260mm (10.25 in)
260mm (10.25 in)
260mm (10.25 in) 3
3
3 on heat sink
on heat sink
on heat sink
Note: On 575 V~(ac) applications, the fuses are mounted external to the QPAC.
QPAC Case Style C.
QPAC Case Style C
Overall Dimensions.
QPAC Case Style C,
QPAC-01, 150, 200, 300A
Single-Phase Mounting
Footprint.
ç
CAUTION:
Mount the QPAC vertically
(height dimension vertical)
for proper cooling. Failure
to do so could result in
power control malfunction.
∫
WARNING: Shock Hazard
Heatsinks are electrically
Live.
330mm
(13.00 in)
178mm
(7.00 in)
10mm (0.38 in)
2 PL
FAN
U
P
MOUNT
89mm
(3.50 in)
299mm
(11.75 in)
92mm
(3.63 in)
Case Style C
Mounting
