QPAC User's Guide 29 Appendix
Accessories
Accessories
Watlow Part Number Model Description
08-5362 Manual Control Kit
16-0176 5A : 20mA Interstage Transformer
0004-0286-0400 400 : 5A Current Transformer
0004-0286-0500 500 : 5A Current Transformer
0004-0286-0600 600 : 5A Current Transformer
0004-0287-0800 800 : 5A Current Transformer
0004-0288-1000 1000 : 5A Current Transformer
16-0008 150A : 5A Current Transformer
16-0045 200A : 5A Current Transformer
16-0073 300A : 5A Current Transformer
Watlow Part
Number
Models Description
17-7053 QPAC 150A up to 480V Fuse, Semiconductor 200A @ 500V Blade, Bussmann FWH-200B
17-7015 QPAC 150A, 575V only Fuse, Semiconductor 200A @ 700V Blade, Bussmann FWP-200A
17-7054 QPAC 200A up to 480V Fuse, Semiconductor 250A @ 500V Blade, Bussmann FWH-250A
17-7016 QPAC 200A, 575V only Fuse, Semiconductor 250A @ 700V Blade, Bussmann FWP-250A
17-7056 QPAC 300A up to 480V Fuse, Semiconductor 400A @ 500V Blade, Bussmann FWH-400A
17-7019 QPAC 300A, 575V only Fuse, Semiconductor 400A @ 700V Blade, Bussmann FWP-400A
17-7057 QPAC 400A up to 480V Fuse, Semiconductor 500A @ 500V Blade, Bussmann FWH-500A
0808-0110-0000 QPAC 400A, 575V only Fuse, Semiconductor 500A @ 500V Blade, Bussmann FWP-500A
17-7058 QPAC 500A up to 480V Fuse, Semiconductor 600A @ 500V Blade, Bussmann FWH-600A
0808-0109-0000 QPAC 500A, 575V only Fuse, Semiconductor 600 A @ 700V Blade, Bussmann FWP-600A
0808-0108-0000 QPAC 600A up to 575V Fuse, Semiconductor 800 A @ 700V Blade, Bussmann FWP-600A
17-7082 QPAC 800A up to 575V Fuse, Semiconductor 1000A @ 700V Blade, Bussmann 170M6714
17-7012 QPAC 1000A up to 575V Fuse, Semiconductor 1250A @ 700V Blade, Bussmann 170M6766
17-5064 QPAC 150 to 300A, 575V
Applications only
Fuse Holder, Semiconductor, externally mounted
08-7210 all Bias and Gain Card, use w/BV Input Control Card
25-0020 QPAC – 150 to 300A Cooling Fan, 115V, 105 CFM 114.3 x 114.3mm (4.5 x 4.5 in)
25-0027 QPAC – 400 to 1000A Cooling Fan, 115V, 260 CFM 152.4mm (6 in)
25-0022 QPAC – 150 to 300A Cooling Fan, 230V, 105 CFM 114.3 x 114.3mm (4.5 x 4.5 in)
25-0028 QPAC – 400 to 1000A Cooling Fan, 230V, 260 CFM 152.4mm (6 in)
18-1064 Q33 – 400 to 600 A Diode, 1400A 1200V, SD1100C..C Series IR
18-1068 Q33 – 1000A Diode, 1170A 1200V, SD1100C..L Series IR
18-1044 Q33 – 150 to 300A Diode, 250A, 1000V, 1N3742R ST
RPC-5405-0000 all DH (Open Heater/Shorted SCR Detector) Card
08-5288 Q01, Q33 Input Control Card, Phase-angle w/AF (4 to 20 mA)
RPC-5411-05-50H Q01, Q33 Input Control Card, Phase-angle, w/AL (0 to 5V Î (dc), 50 Hz)
RPC-5411-05-60H Q01, Q33 Input Control Card, Phase-angle, w/AL (0 to 5V Î (dc), 60 Hz)
RPC-5411-42-50H Q01, Q33 Input Control Card, Phase-angle, w/AL (4 to 20 mA, 50 Hz)
