30 QPAC User's Guide Appendix
Watlow Part
Number
Models Description
RPC-5411-42-60H Q01, Q33 Input Control Card, Phase-angle, w/AL (4 to 20mA, 60 Hz)
08-5289 all Input Control Card, Zero-cross, w/BF (4 to 20mA)
RPC-5342-50HZ all Input Control Card, Zero-cross, w/BV (4 to 20mA, 50 Hz)
RPC-5342-60HZ all Input Control Card, Zero-cross, w/BV (4 to 20mA, 60 Hz)
08-5285 all Input Control Card, Zero-cross, w/CA (ac input)
08-5286 all Input Control Card, Zero-cross, w/CD (dc input)
08-5287 Q01 Motherboard Assembly
08-5320 Q32 Motherboard Assembly
08-5337 Q33 Motherboard Assembly
RPC-5338-150 Q33 all SCR Driver Board 08-5338
18-5052 Q01, Q32 – 150 to 300A SCR Stud, 300A, 1200V, ST
18-5214 QPAC – 400 to 600A SCR, 500A, 1200V, E-PUK
18-5215 QPAC – 800A SCR, 910A, 1200V, HP
18-5216 QPAC – 1000A SCR, 1470A, 1200V, HP
08-5302 QPAC – 150 to 400A, 120V Transformer Assembly, Plug-in, 120V
08-5303 QPAC – 150 to 300A,
208/240V
Transformer Assembly, Plug-in, 208/240V
08-5304 QPAC – 150 to 300A, 277V Transformer Assembly, Plug-in, 277V
08-5306 QPAC – 150 to 300A, 380V Transformer Assembly, Plug-in, 380V
08-5308 QPAC – 150 to 300A, 415V Transformer Assembly, Plug-in, 415V
08-5305 QPAC – 150 to 300A, 480V Transformer Assembly, Plug-in, 480V
08-5307 QPAC – 150 to 300A, 575V Transformer Assembly, Plug-in, 575V
Z100-0818-0000 QPAC – 400 to 1000A, 120V Transformer Assembly, Plug-in, 120V
Z100-0819-0000 QPAC – 400 to 1000A,
208/240V
Transformer Assembly, Plug-in, 208/240V
Z100-0820-0000 QPAC – 400 to 1000A, 277V Transformer Assembly, Plug-in, 277V
Z100-0823-0000 QPAC – 400 to 1000A, 380V Transformer Assembly, Plug-in, 380V
Z100-0822-0000 QPAC – 400 to 1000A, 415V Transformer Assembly, Plug-in, 415V
Z100-0821-0000 QPAC – 400 to 1000A, 480V Transformer Assembly, Plug-in, 480V
Z100-0824-0000 QPAC – 400 to 1000A, 575V Transformer Assembly, Plug-in, 575V
Accessories
