EZ-ZONE PM Limit Express • 28 • Setup Menu
Setup Menu (cont.)
Display Parameter Name Description Range ( Defaults are shown bold)
[`A;LA]
[ A.LA]
Alarm Latching
Turn alarm latching on or off. A latched alarm
has to be turned off by the user.
Appears if: When alarm type is set to process.
[nLAt] Non-Latching
[`LAt]
Latching
`A;bL]
[ A.bL]
Alarm Blocking
Select when an alarm will be blocked. After
startup and/or after the set point changes,
the alarm will be blocked until the process
value enters the normal range.
Appears if: When alarm type is set to process.
[`oFF]
Off
[`Str]
Startup
[StPt]
Set Point
[both]
Both
[`A;si]
[ A.Si]
Alarm Silencing
Turn alarm silencing on to allow the user
to disable the output tied (configured) to
this alarm
Appears if: Always.
[`oFF]
Off
[``on]
On
[A;dSP]
[A.dSP]
Alarm Display
Display an alarm message when an
alarm is active.
Appears if: When alarm type is set to process.
[`oFF] Off
[``on]
On
[PAr1]
[PAr1]
Upper or Left Display
Select parameter to display.
Appears if: Always.
[AC;Pu]
Active Process Value
[none]
None
[PAr2]
[PAr2]
Lower or Right Display
Select parameter to display.
Appears if: Always.
[`Ls;t]
Limit State
[`A;hi]
Alarm High Set Point
[`Lh;S]
Limit High Set Point
[`A;lo]
Alarm Low Set Point
[`LL;S]
Limit Low Set Point
[none]
None
[`ad;s]
[ Ad.S]
Zone Address - Standard Bus Com-
munication
Set zone address from 1-16.
Appears if: Always.
1-16
1
‰
[`loC]
Lockout Menu
[`SEn]
Sensor Type
[`Lin]
Linearization
[``t;C]
Thermistor Curve
[``r;r]
Resistance Range
[`deC]
Decimal
[`C_F]
Display Units
[`r;lo]
Limit Set Point Range Low
[`r;hi]
Limit Set Point Range High
[`fn1]
Function Output One
[`fn2]
Function Output Two
[`l;sd]
Limit Sides
[`l;hy]
Limit Hysteresis
[`A;ty]
Alarm Type
[`A;hy]
Alarm Hysteresis
[`A;lg]
Alarm Logic
[`A;lA]
Alarm Latching
[`A;bl]
Alarm Blocking
[`A;si]
Alarm Silencing
[A;dsp]
Alarm Display
[par1]
Upper or Left Display
[par2]
Lower or Right Display
[`Ad;s]
Zone Address
Setup Menu
To enter the Setup Menu push and hold
the up and down arrow keys for ap-
proximately 3 seconds. Once there, push
the green advance key to scroll through
to the prompt of choice and then use
the up and down arrow keys to change
the range. At any point within the Setup
menu to return to the default display
push the Reset key.
