EZ-ZONE PM Limit Express • 27 • Setup Menu
Setup Menu (cont.)
Display Parameter Name Description Range ( Defaults are shown bold)
[`r;hi]
[ r.hi]
Limit Set Point - Range High
Sets the high limit of the set point adjust-
ment using a T/C and RTD; scales for
process inputs.
Appears if: Always.
-1,999.00 to 9,999.000 °F or Units
-1,110.555 to 5,555.000 °C
[`fn1]
[ fn1]
Function of Output 1
Select which function will drive this output.
Appears if: Always.
[`oFF] Off, [LiM] Limit*, [ALM] Alarm
*Note:
Switched DC/Open Collector option should only be used to control an external mechanical relay if Limit
function is selected.
[`fn2]
[ fn2]
Function of Output 2
Select which function will drive this output.
Appears if: Always.
[`LiM]
Limit
Note:
Output 2 (only) is FM approved as a limit.
[`L;Sd]
[ L.Sd]
Limit Sides
Select which side or sides of the process
value will be monitored.
Appears if: Always.
[both]
Both
[high]
High
[LoW]
Low
[`L;hy]
[ L.hy]
Limit Hysteresis
Set the hysteresis for the limit function. This
determines how far into the safe range the
process value must move before the limit
turns the output back on.
Appears if: Always.
0.001 to 9,999.0°F or units
0.001 to 5,555.0°C
Units, 3.0°F or 2°C
[`A;ty]
[ A.ty]
Alarm Type
Select how the alarm will or will not track
the set point.
Appears if: Always.
[`oFF]
Off
[PR;AL]
Process Alarm
[`A;hy]
[ A.hy]
Alarm Hysteresis
Set the hysteresis for an alarm. This deter-
mines how far into the safe region the pro-
cess value needs to move before the alarm
can be cleared.
Appears if: When alarm type is set to process.
0.001 to 9,999.000°F or units
0.001 to 5,555.000°C
Units, 1.0°F or 1.0°C
[a;lg]
[A.Lg]
Alarm Logic
Select what the output condition will be dur-
ing the alarm state.
Appears if: Always
[`a;lC] Close on Alarm
[`a;lo]
Open on alarm
