Datasheet
©2012 Pro-face. All rights reserved. Specifications may change without notice.
Customer Service Hotline: 800.289.9266
ACCESS www.profaceamerica.com
For more information
Ordering Information
Part Number Description
PFXGP4601TAA GP-4601T: 12.1" TFT Color Touchscreen (Analog), SVGA,
2x Serial, Ethernet, 2x USB, SD, 100-240VAC, UL/CE
PFXGP4601TAD GP-4601T: 12.1" TFT Color Touchscreen (Analog), SVGA,
2x Serial, Ethernet, 2x USB, SD, 24VDC, UL/CE
PFXGP4601TMA GP-4601T: 12.1" TFT Color Touchscreen (Matrix), SVGA,
2x Serial, Ethernet, 2x USB, SD, 100-240VAC, UL/CE
PFXGP4601TMD GP-4601T: 12.1" TFT Color Touchscreen (Matrix), SVGA,
2x Serial, Ethernet, 2x USB, SD, 24VDC, UL/CE
PFXGP4601TAAC GP-4601T: 12.1" TFT Color Touchscreen (Analog), SVGA,
2x Serial, Ethernet, 2x USB, SD, 100-240VAC, UL/CE,
Conformal Coating
PFXGP4601TADC GP-4601T: 12.1" TFT Color Touchscreen (Analog), SVGA,
2x Serial, Ethernet, 2x USB, SD, 24VDC, UL/CE, Conformal
Coating
PFXGP4603TAD GP-4603T: 12.1" TFT Color Touchscreen (Analog), SVGA,
2x Serial (1-RS232, 1-RS485/MPI), Ethernet, 2x USB, SD,
24VDC, UL/CE
GP-460xT - External Dimensions
GP-460xT - Cut-Out Dimensions
Pro-face America
Phone: 734.477.0600
Fax: 734.864.7347
www.profaceamerica.com
DS-GP460xT(B)
Easily Transfer Data
Connectivity
(WKHUQHW
&RQWUROGHYLFH
6ODYH
0DVWHU
6ODYH 6ODYH
(WKHUQHW0XOWL/LQNIXQFWLRQ
7KH(WKHUQHW0XOWL/LQNIXQFWLRQ
DOORZV\RXWRHDVLO\DGGD*3DV
DVXEGLVSOD\WRWKHIDFLOLW\
ZLWKRXWFKDQJLQJDQ\VHWWLQJVRI
WKHFRQWUROGHYLFH
▲
▲
▲
7UDQVIHU7RRO
6'&DUG
86%0HPRU\
(WKHUQHW/$1RU86%FDEOH
7KHGDWDWUDQVIHUWRROFDQEHGRZQORDGHG
IRUIUHHIURPWKH:HE
KWWSZZZSURIDFHDPHULFDFRP
6FUHHQGDWDFDQEHXSGDWHGE\XVLQJWKHGDWDWUDQVIHUWRRO
HYHQZLWKRXWDVRIWZDUHOLFHQVH
Optional Items
Part Number Product Name
PFXZCBSD4GC41 SD Memory Card (4 GB, Class 4)
GP-Pro EX (EX-ED-Vx) Screen and Logic Development Software (ver 3.0 or newer)
PLC Cables & Accessories See AGP3000 Connectivity Document
Caution: Before operating any of these products, please be sure to read all related manuals
thoroughly.
- All product names used in this document are trademarks or registered trademarks of their
respective companies.
- All information contained in this document is subject to change without notice.
Unit: mm [in.]
Unit: mm [in.]
