Ramsey Winch RPH-30000T-117 - Manual (Page 19)

1
1
234183
DRUM ASSY.
2
1
242165
ASSY-FRAME, WINCH MT
G
3
1
265021
T
E
NSIONER-LEVER
4
1
296433
GEAR BOX
ASSY.
5
1
300069
ADAPT
ER-AIR CYLINDER.
6
1
304172
BAR-AIR T
E
NSIONER
7
1
324286
COUPLING-SHAF
T
, 1.375 DIA.
8
1
324288
COUPLING-OUT
PUT
9
1
324298
COUPLING-BRAKE
10
1
338293
END BEARING-GEAR HSG.
11
1
338311
END BEARING-MOT
O
R
12
1
346046
PIN-PIVOT
13
1
357506
SHAF
T
-INPUT
14
1
358065
SHAF
T
-INPUT
SHIF
T
E
R
15
1
365037
T
U
BE-ST
AINLESS, AIR T
ENS. REGULAT
O
R
16
1
365038
T
U
BE-ST
AINLESS, 1/4"DIA, AIR T
ENSIONER
17
2
402119
BEARING
18
1
408227
BRACKET
-ASSY. AIR T
ENSIONER
19
1
412086
BUSHING-T
HRUST
, GEAR HSG.
20
12
414272
SCREW
3/8-16NC
X 5-1/2 HXHD, GR5.
21
2
414278
CAPSCREW 3/8-16NC X
3/4 LG. HX
HD Z/P GR5
22
4
414400
CAPSCREW 3/8-24NF X
4 LG. HX
.HD. GR.8
23
2
414548
CAPSCREW 1/2-13NC X
1-1/2 HX
HD Z/P GR5
24
4
414750
CAPSCREW 3/4-10NC X
1-1/2 LG HX
HD GR5
25
4
414754
CAPSCREW 3/4-10NC X
2-1/2 LG, HX
HD GR5
26
4
414864
CAPSCREW 5/16-18NC X
3/4 LG HX
. SOC HD
27
4
414948
CAPSCREW 1/2-13NC X
1-1/4 LG. HX
. SOC. HD
28
2
414958
CAPSCREW 1/2-13NC X
4 LG. HX
. SOC. HD
29
1
416051
SET
SCREW
5/16-24NF
X 1 LG. SOC. HD. CUP
30
1
416059
SET
SCREW
3/8-16NC X
1/2 LG. HX. SOC. HD. CUP
31
4
416233
SCREW
-#10-24NC X 2 1/2 HX. SOC. HD.
32
2
418069
NUT
1/2-13NC HEX REG. Z
/P
33
4
418080
NUT
5/8-11NC REG HEX Z
/P
34
4
418223
W
ASHER 1/2 USS F
LAT
Z
/P
35
8
418249
LOCKW
ASHER 3/4 ID MED SECT
. Z
/ P
36
2
418
462
W
ASHER
37
1
418432
W
ASHER-T
HRUST
5/16 ID
38
1
418433
NUT
-LOCK 5/16-24NF
X 3/16 T
HK.
39
3
418441
W
ASHER
40
2
418453
SHOULDER BOLT
1/2 X 3/4 LG. 3/8-16
41
2
418456
SHOULDER BOLT
1/2 X 1-1/2 LG. 3/8-16
42
2
424005
COT
T
E
R PIN 1/8 DIA. X 1 LG
43
1
426045
INSERT
-T
HREADED 5/16-24NF
44
1
432023
F
IT
T
ING HYD. 7/16-20 ST
RAIGHT
45
1
432032
F
IT
T
ING-T
EE
46
1
432033
F
IT
T
ING 90 DEG. ELBOW
47
1
432034
F
IT
T
ING 1/8-27 NPT
48
1
F
IT
T
ING-90 DEG. ELBOW
(PARKER #2503-4-4)
49
1
433014
AIR CYLINDER
50
1
433015
REGULAT
O
R-AIR PRESS, PRESET
51
1
433020
REGULAT
O
R-AIR PRESS, ADJUST
ABLE
52
2
433022
AIR ACT
U
AT
OR
53
1
438023
BRAKE
54
1
442216
GASKET
-AIR CYL. ADAPT
ER
55
1
442217
GASKET
-AIR CYL.
56
1
442224
GASKET
-BRAKE
57
1
456008
RELIEF
F
ITTTI
N
G
58
1
456038
F
IT
T
ING-BREAT
HER VENT
59
1
458096
MOT
O
R 2-SPD, 9.6/4.8CID
60
1
462013
QUAD-RING 2-7/8 OD X 2-1/2 I D X 3/16
61
1
462050
QUAD-RING
62
1
462062
O-RING
63
1
468004
REDUCER 1/2-1/8NPT
F
64
2
468016
PIPE PLUG 1/8-
27NPT
F
HEX SOC. HD.
65
1
468019
PIPE PLUG 1/2-14NPT
F
HEX SOC HD.
66
1
470091
PIN-SPRING
67
1
490038
SNAP RING
68
1
494108
SPRING-CLUT
CH SHIF
T
E
R .192 DIA
69
1
509015
T
U
BE ASSY-HYDRAULIC BRAKE RELEASE
70
1
516024
VALVE-MOT
O
R CONT
ROL (24 VOLT
)
1
516025
VALVE-MOT
O
R CONT
ROL (12 VOLT
)
DESC
RI
PT
IO
N
PA
R
T
NO.
QTY.
IT
E
M
DESC
R
IP
T
IO
N
PA
R
T
NO.
QTY
.
ITE
M
17
PARTS LIST
RPH 30000T-117
