Page 4 Paasche A-AU Spray Gun Accessories
Micro Extensions for coating inside small diameters. Will handle most light viscosity fluids. AREH Extended Tip & AJR Extended Aircap Body.
Use: A-AU-3-3/64 Needle (Specify Size 3 up to 12)
A-AU Accessories
79. AEN-45 Elbow
82. AN Nylon Washer
80. AEN-90 Elbow
82. AN Nylon Washer
AE- Extensions (For Fan and Round - Heads Only)
81. AE-3” Extension L/Needle
AE-6” Extension L/Needle
AE-12” Extension L/Needle
AE-18” Extension L/Needle
AE-24” Extension L/Needle
82. AN Nylon Washer
Ax- Stainless Steel Extensions (Ax - Aircaps & Tips Only)
Ax Extensions Complete - Sizes: 3, 6, 12, 18, 24, 36 & 48
83. U-2831- Inner Tube (Select Size)
84. AUF-29 Nut
85. U-2832- Outer Tube (Select Size)
86. AX-1 Tip (Not Included with AX Extensions)
A-AU Extension Needles (Used with AE- & Ax- Extensions)
87. A-AU-3 Extension Needle
A-AU-6 Extension Needle
A-AU-12 Extension Needle
A-AU-18 Extension Needle
A-AU-24 Extension Needle
A-AU-36 Extension Needle
A-AU-48 Extension Needle
Ax Style Aircaps (Used with Ax-Extensions Only)
88. AXR Aircap (External Round Pattern)
89. AXF Aircap (External Fan Pattern)
90. AXIF Aircap (Internal Fan Pattern)
91. AXIF-90 Aircap (Internal Fan Pattern)
92. AXIF-45 Aircap (Internal Fan Pattern)
93. AXIB Aircap (Spherical Pattern)
94. AXI-360 Aircap (Radial Pattern)
95. AXIF-90A Aircap (Internal Fan Pattern)
96. AXIR-15 Aircap (Internal Round Pattern)
97. AXIR-90 Aircap (Internal Round Pattern)
All Ax Aircaps must use a Pressure Feed Cup or Pressure Tank to feed material being sprayed.
Always adjust atomizing air pressure higher than fluid air pressure.
