4.1.3 Peripheral Interface Connectors
200H200H200H203H
Table 4-1 shows a list of the peripheral interface connectors on the
IDDUPS-6364120/636260. Detailed descriptions of these connectors can be found below.
Connector Type Label
ATX mode connector 3-pin wafer connector CN2
ATX power connector
(IDDUPS-6364120A only)
20-pin connector J3
Battery connector 7-pin wafer connector J1, J2
Input power connector 4-pin wafer connector CN1
Output power connector 3-pin wafer connector CN3, CN4
Power switch connector 2-pin wafer connector CN8
RS-232 cable connector 3-pin wafer connector JP2
SBC main power connector
(IDDUPS-636260A only)
5-pin wafer connector CN7
Table 4-1: Peripheral Interface Connectors
4.1.4 Jumper
201H201H201H204H
Table 4-2 lists the jumper on the IDDUPS-6364120/636260. Detailed descriptions of
these jumper can be found in Section
202H202H202H205H
4.3 .
Connector Type Label
AT/ATX mode select jumper 2-pin header JP1
Table 4-2: Rear Panel Connectors
