IDDUPS Series DC/DC Converter Module
Page 11
ƒ Output Voltage:
Voltage (Max Load) +5V +12V -12V +3.3V 5VSB
IDDUPS-6364120A 10A 4A 0.3A 8A 2A
IDDUPS-636260A 10A 3A - - 0.5A
Table 1-1: Output Voltage
ƒ Dimensions: 60mm x 160mm
ƒ Environment:
o Operating temperature: -20°C ~ +85°C
o Storage temperature: -40°C ~ +125°C
ƒ Weight: NW:
o IDDUPS-6364120A: 98g
o IDDUPS-636260A: 75g
1.3 IDDUPS-6364120/636260 Dimensions
190H190H190H193H
Figure 1-1 shows the IDDUPS-6364120/636260 dimensions. The dimensions are given in
millimeters.
Figure 1-1: IDDUPS-6364120/636260 Dimensions (mm)
