AFL-W19A/17D/W15A-N270 Panel PC

Page 33

Figure 2-23: Secure the Panel PC

2.6.5 Panel Mounting (AFL-17D-N270/AFL-W19A-N270)

To mount the panel PC into a panel, please follow the steps below.

Step 1:

Select the position on the panel to mount the flat panel PC.

Step 2:

Cut out a section corresponding to the size shown below. The size must be

smaller then the outer edge. Recommended cutout sizes are shown below.
