AFL-W19A/17D/W15A-N270 Panel PC

Page 25

2.5.8.1 COM3 RS-422 and RS-485 Pinouts

The pinouts for RS-422 and RS-485 operation of external serial port COM 3 are detailed

below.

COM 3

RS-422 Description

Pin 1

TX-

Pin 2

TX+

Pin 6

RX-

Pin 7

RX+

Table 2-11: RS-422 Pinouts

COM 3

RS-485 Description

Pin 1

Data-

Pin 2

Data+

Table 2-12: RS-485 Pinouts

2.6 Mounting the System

WARNING!

The panel PC is very heavy. Two or more people should mount the

panel PC. Dropping or bumping the panel PC during installation can

cause serious or irreparable damage to the panel PC.

The following installation options are available:

2.6.1 Monitor Stand ...................................................................................... 26

2.6.2 Cabinet and Rack ................................................................................ 26

2.6.3 Arm Mounting ...................................................................................... 28

2.6.4 Wall Mounting ...................................................................................... 30

2.6.5 Panel Mounting (AFL-17D-N270/AFL-W19A-N270) ........................... 33

2.6.6 Panel Mounting (AFL-W15A-N270)..................................................... 35
