IDS-H61 Digital Signage Player
Page 48
6.2.2 Fan Connector (FAN2)
PIN NO. DESCRIPTION
1 GND
2 +12V
3 FB
4 PWM
Table 6-3: Fan Connector (FAN2) Pinouts
6.2.3 Half-Size PCIe Mini Slot (CN3)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 PCIE-WAKE 2 +3.3V
3 N/C 4 GND
5 N/C 6 +1.5V
7 N/C 8 N/C
9 GND 10 N/C
11 PCIE_CLK- 12 N/C
13 PCIE_CLK+ 14 N/C
15 GND 16 N/C
17 RESET 18 GND
19 N/C 20 +3.3V
21 GND 22 RESET
23 PCIE_RN4 24 +3.3V
25 PCIE_RP4 26 GND
27 GND 28 +1.5V
29 GND 30 SMB_CLK
31 PCIE_TN4 32 SMB_DATA
33 PCIE_TP4 34 GND
35 GND 36 -USBP
37 GND 38 +USBP
39 +3.3V 40 GND
41 +3.3V 42 N/C
