4.3.3 H/W Monitor
The H/W Monitor menu (BIOS Menu 5) contains the fan configuration submenus and
displays operating temperature, fan speeds and system voltages.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
PC Health Status
Smart Fan Function [Enable]
CPU Temperature
:+30 C
CPU FAN Speed
:N/A
V_CORE
: +1.072 V
V_3.3 : +3.392 V
+1.05V : +1.064 V
Vcc1_5VDDR : +1.600 V
5VSB : +4.944 V
VCC3V : +3.376 V
VSB3 : +3.408 V
VBAT : +2.992 V
Smart Fan Mode Select
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.15.1226. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 5: H/W Monitor
Î Smart Fan Function [Enable]
Use the Smart Fan Function option to disable or enable the Smart Fan.
Î
Disable The smart fan is disabled.
Î
Enable D EFAULT
The smart fan is enabled.
Î H/W Monitor
The following system parameters and values are shown. The system parameters that are
monitored are:
