IDS-H61 Digital Signage Player
Page 16
Figure 3-7: Installing the HDD
Step 6: Connect the SATA cable to the SATA connector and SATA power connector on
the motherboard.
Step 7: Reinstall the top cover.
3.4 Mounting the System
To mount the IDS-H61 onto a wall, please follow the steps below.
Step 1: Select the location on the wall for mounting the IDS-H61.
Step 2: Carefully mark the locations of the four mounting screw holes on the wall. Drill
four pilot holes at the marked locations on the wall for the bracket retention
screws.
Step 3: Align the wall-mounting screw holes of the mounting bracket with the pilot holes.
Secure the mounting bracket to the wall by inserting the retention screws into
the four pilot holes and tightening them (Figure 3-8).
