IDS-H61 Digital Signage Player
Page 19
ƒ USB devices
To install these devices, connect the corresponding cable connector from the actual
device to the corresponding IDS-H61 external peripheral interface connector making sure
the pins are properly aligned.
3.5.1 Audio Line-out Connector
CN Label: Audio out
CN Type:
Audio jack
The audio line-out jack connects to a headphone or a speaker. With multi-channel
configurations, this port can also connect to front speakers.
3.5.2 DisplayPort Connector
CN Label: DisplayPort
CN Type:
DisplayPort 1.1
The DisplayPort connector transmits a digital signal to compatible DisplayPort display
devices such as a TV or computer screen.
3.5.3 LAN Connector
CN Label: LAN
CN Type: RJ-45
CN Pinouts: See Table 3-1
The LAN connector allows connection to an external network.
Pin Description Pin Description
1 TRD1P0 5 TRD1P2
2 TRD1N0 6 TRD1N2
3 TRD1P1 7 TRD1P3
4 TRD1N1 8 TRD1N3
Table 3-1: LAN Pinouts
