TANK-720 Em b e d d e d S ys te m
P a g e 75
4.4.1 No rth Brid g e
Use the North Bridge menu (BIOS Menu 17) to configure the Northbridge chipset.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Chipset
Memory Information
Total Memory
2048 MB (DDR3 1333)
Memory Slot
0 MB (DDR3 1333)
Onboard Memory 2048 MB (DDR3 1333)
> Intel IGD SWSCI OpRegion
Config Graphics
Settings.
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1
General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 17: Northbridge Chipset Configuration
4.4.1.1 In te l IGD S WS CI Op Re g io n
Use the Intel IGD SWSCI OpRegion menu (BIOS Menu 18) to configure the graphics
options.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Chipset
Intel IGD SWSCI OpRegion
DVMT Mode Select
[DVMT Mode]
DVMT/FIXED Memory [256MB]
Select DVMT Mode used by
Internal Graphics
Device.
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1
General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 18: Graphics Configuration
 DVMT Mode Se le c t [DVMT Mode ]
