TANK-720 Em b e d d e d S ys te m
P a g e 70

IO=2D0h;
IRQ=10, 11
Serial Port I/O port address is 2D0h and the interrupt
address is IRQ10, 11

IO=2D8h;
IRQ=10, 11
Serial Port I/O port address is 2D8h and the interrupt
address is IRQ10, 11

IO=2E0h;
IRQ=10, 11
Serial Port I/O port address is 2E0h and the interrupt
address is IRQ10, 11
 De vic e Mode [RS422/485]
Use the Device Mode option to set the serial port to normal or RS-422/485
communications..

Normal Sets the serial port mode to normal.

RS422/485 D EFAULT Enables serial port RS-422/485 support.
4.3.8 H/W Mo n ito r
The H/W Monitor menu (BIOS Menu 13) shows the operating temperature, fan speeds
and system voltages.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
PC Health Status
CPU Temperature
:+72 C
System Temperature :+40 C
V3.3S :+3.312 V
CPU_CORE :+0.984 V
+V5S :+4.880 V
+12VS :+12.056 V
+1.5V_DDR3 :+1.624 V
VSB3V :+3.360 V
VBAT :+3.296 V
5VSB :+5.160 V
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1
General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 13: H/W Monitor
