TANK-800 Embedded System
Page 67
Î
Disabled D EFAULT
The spread spectrum mode is disabled
Î
Enabled The spread spectrum mode is enabled
4.4.3 Intel IGD SWSCI OpRegion
Use the Intel IGD SWSCI OpRegion menu (BIOS Menu 15) to configure the video device
connected to the system.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Chipset
Intel IGD SWSCI OpRegion Configuration
DVMT Mode Select
[DVMT Mode]
DVMT/Fixed Memory [Maximum]
Select DVMT Mode/Fixed
Mode
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 15: Intel IGD SWSCI OpRegion Configuration
Î DVMT Mode Select [DVMT Mode]
Use the DVMT Mode Select option to select the Intel Dynamic Video Memory Technology
(DVMT) operating mode.
Î
Fixed Mode
A fixed portion of graphics memory is reserved as
graphics memory.
Î
DVMT Mode D EFAULT
Graphics memory is dynamically allocated according
to the system and graphics needs.
Î DVMT/FIXED Memory [Maximum]
Use the DVMT/FIXED Memory option to specify the maximum amount of memory that
can be allocated as graphics memory. Configuration options are listed below.
