TANK-800 Embedded System
Page 3
1.2 Model Variations
The model variations of the TANK-800 Series are listed below.
Model No. CPU Expansion Slots
TANK-800-R10/D525/1GB/2P1E Intel® Atom™ D525 1.8 GHz
dual core
Two PCI slots
One PCIe x4 slot
TANK-800-R10/D525/1GB/1P2E Intel® Atom™ D525 1.8 GHz
dual core
One PCI slot
One PCIe x1 slot
One PCIe x2 slot
Table 1-1: TANK-800 Model Variations
1.3 Features
The TANK-800 features are listed below:
ƒ Intel® Atom™ D525 1.8 GHz dual core processor
ƒ 1.0 GB of DDR3 SDRAM SO-DIMM preinstalled
ƒ Redundant dual DC input
ƒ Flexible PCI/PCIe expansion slots
ƒ Two Gigabit Ethernet ports
ƒ Four USB 2.0 ports
ƒ Four RS-232 serial ports
ƒ Two RJ-45 RS-422/485 serial ports
ƒ One VGA port
ƒ One Line-out and one Mic-in audio jacks
ƒ One CompactFlash® Type II socket
ƒ AT/ATX power mode supported
ƒ RoHS compliant
