4.3.2 CPU Configuration
Use the CPU Configuration menu (BIOS Menu 4) to view detailed CPU specifications
and configure the CPU.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
CPU Configuration
Processor Type
Intel(R) Atom(TM)
CPU D525 @ 1.80GHz
EMT64 Supported
Processor Speed 1800 MHz
System Bus Speed 800 MHz
Ratio Status 9
Actual Ratio 9
Processor Stepping 106CA
Microcode Revision 263
L1 Cache RAM 2x56 K
L2 Cache RAM 2x512 K
Processor Core Dual
Hyper-Threading Supported
Hyper-Threading [Enabled]
Enabled for Windows XP
and Linux (OS optimized
for Hyper-Threading
Technology) and Disabled
for other OS (OS not
optimized for
Hyper-Threading
Technology).
----------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 4: CPU Configuration
The CPU Configuration menu (BIOS Menu 4) lists the following CPU details:
ƒ Processor Type: Lists the brand name of the CPU being used
ƒ EMT64: Indicates if the EM64T is supported by the CPU.
ƒ Processor Speed: Lists the CPU processing speed
ƒ System Bus Speed: Lists the system bus
ƒ Ratio Status: List the maximum FSB divisor
ƒ Actual Ratio: Lists current FSB divisor
ƒ Processor Stepping: Lists the CPU processing stepping
ƒ Microcode Revision: Lists the microcode revision
ƒ L1 Cache RAM: Lists the CPU L1 cache size
ƒ L2 Cache RAM: Lists the CPU L2 cache size
ƒ Processor Core: Lists the number of the processor core
