KINO-QM770 Mini-ITX SBC
Page 8
Serial Ports Two RS-232 COM connectors (one by pin header, one on rear side)
One RS-422/485 COM connector (4-pin wafer)
USB Ports Four internal USB 2.0 ports (by two 8-pin header)
Four external USB 3.0 ports
SMBus One 4-pin wafer connector
Storage
SATA 2 x SATA 3Gb/s
2 x SATA 6Gb/s with RAID 0/1/5/10 support
Environmental and Power Specifications
Power Supply 12V only, AT/ATX support
Power Connector 1 x External 4-pin DIN DC jack
1 x Internal 4-pin (2x2) power connector
Power Consumption [email protected] (2.30GHz Intel® Core™ i7-3610QE CPU with two 4GB
1333MHz DDR3 memory running 3DMark06 burn-in)
Operating Temperature -10ºC ~ 60ºC (32ºF ~ 140ºF)
Storage Temperature -20ºC ~ 70ºC
Operating Humidity 5% ~ 95% (non-condensing)
Physical Specifications
Dimensions 170 mm x 170 mm
Weight GW/NW 900 g/450 g
Table 1-1: Technical Specifications
