5.3.11.1 Smart Fan Mode Configuration
Use the Smart Fan Mode Configuration submenu (BIOS Menu 15) to configure the
smart fan temperature and speed settings.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Smart Fan Mode Configuration
CPU Fan Smart Fan Control [Auto Mode]
Fan start temperature 50
Fan off temperature 40
Fan start PWM 30
Fan slope PWM 1
SYS Fan Smart Fan Control [Auto Duty-Cycle Mode]
Temperature 1 60
Temperature 2 50
Temperature 3 40
Temperature 4 30
Smart Fan Mode Select
(Reference System
Temperature)
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 15: Smar Fan Mode Configuration
Î CPU Fan Smart Fan Control [Auto Mode]
Use the CPU_FAN1 Smart Fan Control option to configure the CPU Smart Fan
(CPU_FAN1).
Î
Manual Mode The fan spins at the speed set in Manual by Duty
Cycle settings
Î
Auto Mode D EFAULT The fan adjusts its speed using Auto by
Duty-Cycle settings
