5.3.6.2 Parallel Port Configuration
Use the Parallel Port Configuration menu (BIOS Menu 10) to configure the serial port n.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
Parallel Port Configuration
Parallel Port [Enabled]
Device Settings IO=378h; IRQ=5
Change Settings
[Auto]
Device Mode [Standard Parallel..]
Enable or Disable
Parallel Port (LPT/LPTE)
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4 Save
ESC Exit
Version 2.01.1204. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 10: Parallel Port Configuration Menu
Î Parallel Port [Enabled]
Use the Parallel Port option to enable or disable the parallel port.
Î
Disabled Disable the parallel port
Î
Enabled D EFAULT Enable the parallel port
Î Change Settings [Auto]
Use the Change Settings option to change the parallel port IO port address and interrupt
address.
Î
Auto D EFAULT The parallel port IO port address and interrupt
address are automatically detected.
Î
IO=378h;
IRQ=5
Parallel Port I/O port address is 378h and the
interrupt address is IRQ5
