PICOe-HM650 Half-size PCIe CPU Card
Page 15
Connector Type Label
Battery connector 2-pin wafer BAT1
CPU power connector 4-pin connector CPU12V1
DDR3 SO-DIMM 204-pin SO-DIMM DIMM1, DIMM2
Digital input/output (DIO) connector 10-pin header DIO1
EC debug connector 20-pin FPC connector CN6
Fan connector (CPU) 4-pin wafer CPU_FAN1
Fan connector (system) 4-pin wafer SYS_FAN1
Front panel connector 10-pin header F_PANEL1
I
2
C connector 4-pin wafer CN7
Infrared connector 5-pin header IR1
Inverter connector 5-pin wafer INVERTER1
Keyboard and mouse connector 6-pin wafer KB_MS1
LVDS connector 30-pin crimp LVDS1
Parallel port connector 26-pin header LPT1
SATA 6Gb/s connector 7-pin SATA S_ATA1, S_ATA2
SATA 3Gb/s connector 7-pin SATA S_ATA3, S_ATA4
Serial port connectors (RS-232) 10-pin header COM1, COM2
Serial port connector (RS-422/485) 4-pin header COM3
SMBus connector 4-pin wafer CN5
SPI flash connector (BIOS) 8-pin header JSPI1
SPI flash connector (EC) 8-pin header JSPI2
TPM connector 20-pin header TPM1
USB 2.0 connector 8-pin header USB1, USB2, USB3
Table 3-1: Peripheral Interface Connectors
