PICOe-HM650 Half-size PCIe CPU Card
Page 7
Specification PICOe-HM650
Serial Ports Two RS-232 serial ports via internal 10-pin header
One RS-422/485 serial ports via internal 4-pin wafer
USB 2.0 ports Two external USB ports
Six USB ports via internal pin headers
Parallel Port One 26-pin header
Infrared One 5-pin header
Keyboard/Mouse One keyboard and mouse connector via internal 6-pin header
SMBus One 4-pin wafer connector
I
2
C One 4-pin wafer connector
Fan One 4-pin wafer smart fan connector
One 3-pin wafer system fan connector
TPM One 20-pin header supports optional Infineon TPM module
Storage
Serial ATA Two SATA 6Gb/s ports
Two SATA 3Gb/s ports
Environmental and Power Specifications
Power Supply 5 V / 12 V, AT/ATX power support
Power Consumption [email protected], [email protected], [email protected], [email protected] (2.7GHz
Intel® Core™ i7-2620M with two 2GB 1333MHz DDR3 memory)
Operating Temperature -10
°C~60°C
Storage Temperature -20
°C~70°C
Humidity 5% ~ 95% (non-condensing)
Physical Specifications
Dimensions 185 mm x 122 mm
Weight GW/NW 1000g/260g
Table 1-1: Technical Specifications
