PICOe-HM650 Half-size PCIe CPU Card
Page 74
5.2 Main
The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered.
The Main menu gives an overview of the basic system information.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
BIOS Information
BIOS Vendor
American Megatrends
Core Version 4.6.4.0 0.01
Compliency UEFI 2.1
Project Version B214AR10.ROM
Build Date and Time 01/02/2012 11:05:12
iWDD Vendor
ICP
iWDD Version B214ER12.bin
System Date
[Tue 03/04/2011]
System Time [15:10:27]
Access Level Administrator
Set the Date. Use Tab to
switch between Data
elements.
----------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 1: Main
Î System Overview
The BIOS Information lists a brief summary of the BIOS. The fields in BIOS Information
cannot be changed. The items shown in the system overview include:
ƒ BIOS Vendor: Installed BIOS vendor
ƒ Core Version: Current BIOS version
ƒ Project Version: the board version
ƒ Build Date: Date the current BIOS version was made
The System Overview field also has two user configurable fields:
Î System Date [xx/xx/xx]
Use the System Date option to set the system date. Manually enter the day, month and
year.
