PICOe-HM650 Half-size PCIe CPU Card
Page 6
1.5 Technical Specifications
PICOe-HM650 technical specifications are listed in table below.
Specification PICOe-HM650
Form Factor Half-size PCIe CPU Card
CPU Socket Socket G2
CPU Options Intel® Core™ i7/i5/i3 quad-core/dual-core processor
Intel® Celeron® processor
System Chipset Intel® HM65
Graphics Engine Intel® HD Graphics Gen 6 support for DX10.1 and OpenGL 3.0
Full MPEG2, VC1, AVC Decode
Memory Two 204-pin SO-DIMM sockets support two 1333/1066 MHz DDR3
SDRAM SO-DIMM (system max. 16 GB)
Ethernet Controller Two Realtek RTL8111E PCIe GbE controllers
(LAN1 with ASF2.0 support)
BIOS UEFI BIOS
Super I/O Fintek F81866
Embedded Controller ITE IT8519E
PCIe to PCI Bridge Controller ITE IT8892E
Digital I/O 8-bit digital I/O (4-bit input, 4-bit output)
Watchdog Timer Software programmable supports 1~255 sec. system reset
Expansion
PCI PCI signal via golden finger
PCIe Four PCIe x1 via golden finger
I/O Interface Connectors
Display One VGA port (VGA integrated in Intel® HM65)
18/24-bit dual-channel LVDS
Ethernet Two RJ-45 GbE ports
Audio Supports 7.1 channel HD audio via optional IEI AC-KIT-888HD kit
