PCIE-Q670 PICMG 1.3 CPU Card

Page 54

4.4 Chassis Installation

4.4.1 Airflow

WARNING:

Airflow is critical to the cooling of the CPU and other onboard

components. The chassis in which the PCIE-Q670 Series must have

air vents to allow cool air to move into the system and hot air to move

out.

The PCIE-Q670 Series must be installed in a chassis with ventilation holes on the sides

allowing airflow to travel through the heat sink surface. In a system with an individual

power supply unit, the cooling fan of a power supply can also help generate airflow

through the board surface.

4.4.2 CPU Card Installation

To install the CPU card onto the backplane, carefully align the CPU card edge connector

with the CPU card socket on the backplane. To do this, please refer to the reference

material that came with the backplane. Next, secure the CPU card to the chassis. To do

this, please refer to the reference material that came with the chassis.

4.5 Internal Peripheral Device Connections

This section outlines the installation of peripheral devices to the onboard connectors.

4.5.1 Dual RS-232 Cable with Slot Bracket

The dual RS-232 cable slot connector consists of two connectors attached to two

independent cables. Each cable is then attached to a D-sub 9 male connector that is

mounted onto a slot. To install the dual RS-232 cable, please follow the steps below.

Step 1:

Locate the connectors. The locations of the RS-232 connectors are shown in

Chapter 3.
