62
-
Alarm Out Time
Set the amount of time (in second) to continue sending the alarm once activated
(3) Sensor Setup
-
Sensor Status
Customize the initial state of the attached sensor for every camera. Refer to the table below
to customize the sensor state.
Not installed: Indicates that there is no sensor connected
Normal open: Indicates that the initial state of the sensor is normal open. Video
recording initiate when there is a changes in the sensor state
Normal close: Indicates that the initial state of the sensor is normal close. Video
recording initiate when there is a changes in the sensor state
-
Sensor Record Time
Set the amount of time (in second) to record after the sensor has been triggered
(4) Spot Monitor
To display channel alarm event in full screen mode when the sensor is activated or motion is
detected. When there are multiple alarm events, DVR system will display the last alarm event.
-
Sensor
Select the channel that will send out the alarm event for display when the sensor has been
triggered.
-
Motion
Select the channel that will send out the alarm event for display when the motion has been
detected.
-
Camera
Select the channel to display alarm event.
-
Call Monitor Time
Set a period time (0 ~ 255 sec) for alarm event to display on surveillance screen.
