31
OSD MENU Description
MAIN MENU
CAMERA
RECORD
HARD DRIVE
SENSOR / ALARM
MOTION
NETWORK
BACKUP
SYSTEM
SENSOR / ALARM
To setup sensor and alarm relate parameters.
10 SEC
010 SEC
SENSOR / ALARM SETUP
SENSOR
ALARM
SENSOR RECORD TIME
ALARM OUT TIME
SPOT MONITOR
SENSOR RECORD TIME
Set the amount of time (in second) to start record when the
sensor has triggered
ALARM OUT TIME
Set the amount of time (in second) to continue sending the alarm
once triggered
NOT INSTALLED
NOT INSTALLED
NOT INSTALLED
NOT INSTALLED
SENSOR SETUP
CHANNEL - 1
CHANNEL - 2
CHANNEL - 3
CHANNEL - 4
NOT INSTALLED
NOT INSTALLED
NOT INSTALLED
NOT INSTALLED CHANNEL - 5
CHANNEL - 6
CHANNEL - 7
CHANNEL - 8
NOT INSTALLED
NOT INSTALLED
NOT INSTALLED
NOT INSTALLED CHANNEL - 9
CHANNEL - 10
CHANNEL - 11
CHANNEL - 12
NOT INSTALLED
NOT INSTALLED
NOT INSTALLED
NOT INSTALLED CHANNEL - 13
CHANNEL - 14
CHANNEL - 15
CHANNEL - 16
SENSOR SETUP
CHANNEL 1~16 :
Customize the initial state of the attached sensor. Refer to the
table below to customize the sensor state
Condition Description
NOT
INSTALLED Indicates that there is no sensor
connected
NORMAL
OPEN Indicates that the initial state of the
sensor is normal open. Video recording
initiates when there is a changes in the
sensor state
NORMAL
CLOSE Indicates that the initial state of the
sensor is normal close. Video recording
initiates when there is a changes in the
sensor state
10 SEC
010 SEC
SENSOR / ALARM SETUP
SENSOR
ALARM
SENSOR RECORD TIME
ALARM OUT TIME
SPOT MONITOR
ALARM SETUP
ALARM SETUP
ALARM OUT
BUZZER
ON
SENSOR
MOTION
VIDEO LOSS
HDD FAIL
COPY SETTING VALUE TO BUZZER
1 2 3 4
9 10 11 12
5
13
6
14
7
15
8
16
1 2 3 4
9 10 11 12
5
13
6
14
7
15
8
16
1 2 3 4
9 10 11 12
5
13
6
14
7
15
8
16
ALARM OUT:
Select the way of alarming – BUZZER, RELAY-1, RELAY-2,
RELAY-3, RELAY-4, or ALL.
SENSOR:
Select the channel that will be send out the alarm when sensor
has been triggered
