AVerMedia Technologies AVERDIGI EB5416DVD User Manual
Page 18
12
1.5.4.3
RS485 Pin Definition
When connect PTZ camera through RS485 interface, please refer to the following pin
definition to connect the DVD and PTZ.
Pin #
DVR
PTZ
TX+
RS485 TX+ signal
RS485 RX+ signal
TX-
RS485 TX- signal
RS485 RX- signal
RX+
RS485 RX+ signal
RS485 TX+ signal
RX-
RS485 RX- signal
RS485 TX- signal
