Page 2

If you have any questions, please give us a call. Call Toll Free 1-800-456-7865

WEATHER GUARD® products are protected by one or more of the following patents or trademarks:

U.S. - 842268, 1661625, 1663369; Canada - 282725; U.K. - 1400720; other patents and trademarks pending.

- NOTICE -

Any modification or unintended use of this product shall immediately void all manufacturer’s warranties.
Manufacturer disclaims all liability for injuries to persons or property resulting from any modification to, or
unintended use of this product, including, but not limited to, the storage or transfer of flammables, explo-
sives, hazardous materials, or hazardous waste in this product.

CAUTION

To keep debris out of your
eyes when checking the
underside of the vehicle, or
when drilling, always wear
protective eyewear.

WARNING

Prior to drilling, so as not to
cut or puncture fuel tanks, fuel
lines, brake lines, electric
wires, etc., check under vehi-
cle for locations.

CAUTION

If welding is to be done on the
vehicle chassis, disconnect
the cables from the battery, to
prevent shorting out electrical
components on the vehicle.

TYPE A

Type "A" brackets to be mounted at the

front and rear edge of Underbed Box

TYPE B

All steel and aluminum boxes must

be mounted with either Type "A" or

Type "B" brackets

A third Type "A" bracket should be

used in the center of 24" deep

Underbeds

A third cross brace should be used in

the center of the Type "B" bracket

when mounting a 24" deep Underbed

Under Body Mounting

The box must be mounted
as shown or structural dam-
age will occur to the box.

Stake Bed Top

Mounting

The box must be mounted
with the bottom fully sup-
ported or structural damage
will occur to the box.

(Model 626 shown)

KNAACK MANUFACTURING COMPANY

420 E. TERRA COTTA AVENUE - CRYSTAL LAKE, ILLINOIS, 60014

815-459-6020
