Anti-rotation example – Warner Electric TG-2000 MagStop Clutch_Brake User Manual
Page 8
8
Warner Electric • 800-825-9050
P-1177 • 819-0457
Incorrect
A1
Make Sure That This
Area Does Not Contact
Field Shell
.125 Min.
Do Not Orient So That
Bracket Will Bind In Slot
Do Not Bottom In Slot
Correct
.030 Min.
Loose Fit
.060 Min.,
Worst Case Stackup
Must Not Allow
Bottoming In Slot
A1
A1
Incorrect
A1
Make Sure That This
Area Does Not Contact
Field Shell
.125 Min.
Do Not Orient So That
Bracket Will Bind In Slot
Do Not Bottom In Slot
Correct
.030 Min.
Loose Fit
.060 Min.,
Worst Case Stackup
Must Not Allow
Bottoming In Slot
A1
A1
Anti-Rotation Example
