3.3.5. Printing or Viewing Timing Results
Follow the steps below to print or view the timing results after performing a circuit breaker
timing test:
a. After performing a timing test you will be returned to the “START-UP” menu:
Press the
[2]
key (GET RESULTS).
b. The following screen will be displayed:
1. PRINT TEST RESULTS
Press the
[1]
key (PRINT TEST RESULTS) to view the test results on the screen or to
print the tabulated test results WITHOUT the graph. The following screen will be
displayed:
Press the
[1]
key (THERMAL PRINTER) to print the tabulated test results on the
built-in thermal printer. The tabulated results will be printed, and you will be
returned to the “START-UP” menu. A typical tabulated results printout is shown in
Figure 22.
SELECT PRINTER
1. THERMAL PRINTER
2. DISPLAY RESULTS
1. PRINT TEST RESULTS
2. PLOT FULL CHART
3. PLOT EXPANSION
4. PLOT 0 - 200MS
1. TIME BREAKER 09/16/13
2. GET RESULTS 10:10:10
3. SAVE/RESTORE
4. SETUP
5. DIAGNOSTICS
