REV 1 CT-7000 S3 USER’S MANUAL
34
3.2.7. Configuring the Channel Settings
The CT-7000 S3 is available with 3 or 6 contact inputs. Since most common timing applications
require the use of only 3 contact timing channels and one travel transducer channel, there is no
need to print data for more than 3 timing channels and one transducer channel on the graphic
and tabulated reports. The CT-7000 S3 is configured to print 3 contact channels by default
(channels 1, 2, and 3) and one transducer channel (transducer channel #1). The default settings
can be changed using the steps below:
NOTE
The CT-7000 S3 will always acquire data for all channels and store it in the working
memory when a test is performed.
a. Start from the “START-UP” menu:
Press the
[4]
key (SETUP).
b. The following screen will be displayed:
Press the
[4]
key (NUMBER OF CHANNELS).
c. The following screen will be displayed:
NOTE
The number of channels listed on this screen depends on the CT-7000 S3
model. For example, if your unit has only 3 channels (Model CT-7000 S3-3), only
option 1 (3 Contacts) will be available.
NUMBER OF CHANNELS
1. 3 CONTACTS
2. 6 CONTACTS
1. ANALYSIS POINTS
2. MEASUREMENT UNITS
3. SHOT DESCRIPTION
4. NUMBER OF CHANNELS
5. NEXT PAGE
1. TIME BREAKER 09/12/13
2. GET RESULTS 10:10:10
3. SAVE/RESTORE
4. SETUP
5. DIAGNOSTICS
