REV 1 CT-7000 S3 USER’S MANUAL
100
3.5.4. Printing a Breaker Test Plan Stored in the CT-7000's Memory
Follow the steps below to print a breaker test plan stored in the CT-7000 S3’s Flash EEPROM:
a. Start from the “START-UP” menu:
Press the
[4]
key (SETUP).
b. The following screen will be displayed:
Press the [1] key (ANALYSIS POINTS).
c. The following screen will be displayed:
Press the
[4]
key (TEST PLANS).
d. The following screen will be displayed:
Press the [2] key (PRINT TEST PLAN).
1. LOAD TEST PLAN
2. PRINT TEST PLAN
3. PRINT PLAN DIR
4. ERASE TEST PLAN
5. SAVE TEST PLAN
1. OPEN TIMING
2. CLOSE TIMING
3. PRINT SETTINGS
4. TEST PLANS
1. ANALYSIS POINTS
2. MEASUREMENT UNITS
3. SHOT DESCRIPTION
4. NUMBER OF CHANNELS
5. NEXT PAGE
1. TIME BREAKER 09/18/13
2. GET RESULTS 10:10:10
3. SAVE/RESTORE
4. SETUP
5. DIAGNOSTICS
