Operator's Manual
Efficiency Test Procedure
1. From the menu bar, choose Analysis > Power Analysis.
2. Check Enable.
3. On the Power Analysis dialog choose Performance Analysis and Efficiency Test.
4. Choose the Input Voltage, Input Current, Output Voltage and Output Current channels.
5. Optionally, select Statistics to display mean, minimum and maximum values on the measurements
table. This helps to observe a consistent number.
6. Optionally, select Histicons to display a miniature histogram of the statistical measurements.
921326 Rev B 29
