TIP: You may need to open the Line Harmonics or Current per Watt dialogs to adjust the zoom of the
trace.

To see the harmonics readout in the measurements table:

l

Stop acquisition by pressing the front panel Stop trigger button.

l

Choose Cursor > Horizontal Abs from the menu bar.

l

Turn the front panel Cursor knob or touch-and-drag the white cursor line to move it along the
line harmonics trace.
