The scripts may be opened and run from this directory for systems equipped with the
UWBTrainer exerciser module.
Test Case 1.1: TD.8.2.3.2 Beacon Join With BP Length Expansion
This test verifies that the DUT sets the slot states correctly in the Beacon Slot Info
bitmap. Test system starts the beacon period and sends a beacon in slot 2 with a BP
Length of 3. When the DUT powers on, it should join the beacon group in an available
upper slot and signal (4 on – 4 off) in random signaling slot to extend the BP Length.
Test procedure
1. Start analyzer capture.
2. Test system starts the beacon period and sends a beacon in slot 2 with a BP
Length of 3.
3. Standard test start-up sequence.
4. After 1 second, test system stops beaconing.
5. After at least 2 seconds, stop analyzer capture.
Notes:
• Background observation checks verify DUT & INTD follow correct signaling
and slot contraction behavior.
• This test is repeated with the DUT/INTD on TFC’s 1 through 7 during WiMedia
Platform Certification tests.
Test Case 1.2: TD.7.8.3 Beacon Slot Info Test
This test verifies that the DUT does not incorrectly change its BPOIE. The tester starts by
beaconing normally as a single device in slot 2. It then skips beacon transmission in a single
superframe X. The test system sends a beacon normally in superframe X+1 with the movable
bit set to zero. The test system then sends a beacon in superframe X+2 with the movable bit
set to one. Finally, the test system sends a beacon with an invalid FCS in superframe X+3. It
repeats this sequence 100 times each time skipping after sending the 3
rd
beacon with an FCS
error. The DUT and INTD should not change their current slot or movable status throughout
this test.
Test procedure
1. Start analyzer capture.
2. Standard test start-up sequence.
3. The test system creates the beacon group in slot 2 as a single device. The BP
Length is set to 12.
