UWBSpekChek™ WiMedia Platform Compliance
Test Guide
rev3.10 2 Page 3 of 33
Tool Bar:
Create new compliance project.
Open existing compliance project.
Save current compliance project.
Open output folder. Saved samples and logs are saved in this folder.
Run selected scripts.
Stop running of selected scripts.
Show settings dialog.
Show about dialog.
Status Bar:
UWBSpekChek Status:
Current status of application is shown in this pane. Possible status messages
are: “Connecting to Server”, “Capturing sample file”, and “Verifying script”.
Analyzer Status:
Hardware analyzer status is shown in this pane.
Generation Status:
Hardware generation status is shown in this pane.
Results Statistical Report:
Shows brief statistical report of current run.
